A deep dive into building Eclipse — the security layer of DotGhostBoard: AES-256-GCM encryption, master password lock screen, stealth mode, secure delete, and app filtering. Full code walkthrough.
Watch the 1-minute overview:
👻 DotGhostBoard v1.4.0 — Eclipse
TL;DR — I built a clipboard manager for Linux (PyQt6 + SQLite) and just shipped its security layer: AES-256-GCM encryption, a master password lock screen, per-item secret toggle, stealth mode, secure file deletion, and app-level capture filtering. Zero telemetry. Zero Electron. 100% Python.
Background — Why Another Clipboard Manager?
Every clipboard manager I tried on Kali was either too heavy (Electron), too basic, or required a network connection. I wanted something that:
- Runs lean on Kali Linux with no browser runtime
- Captures text, images, and video paths automatically
- Has a proper security layer — not just a toggle
So I built DotGhostBoard as part of my DotSuite toolkit. It’s been through four versions:
| Version |
Codename |
Focus |
| v1.0 |
Ghost |
Core capture + SQLite + dark UI |
| v1.1 |
Phantom |
Global hotkey + autostart |
| v1.2 |
Specter |
Image thumbnails + video preview |
| v1.3 |
Wraith |
Tags, collections, multi-select |
| v1.4 |
Eclipse |
Security — encryption, lock, stealth |
What’s in Eclipse
v1.4.0 Eclipse
├── 🔐 AES-256-GCM encryption engine
├── 🔑 Master password (PBKDF2-SHA256, 600K iterations)
├── 🔒 Lock screen — frameless, Escape-proof
├── 👁 Per-item secret toggle (right-click → Mark as Secret)
├── ⏱ Auto-lock after N minutes of inactivity
├── 👁 Stealth mode — hide from taskbar + Alt+Tab
├── 🗑 Secure delete — multi-pass byte overwrite
└── 🛡 App filter — whitelist / blacklist by process name
The Crypto Engine
The hardest design decision was key management. I didn’t want to store the password anywhere — only a verifier that proves the password is correct.
# core/crypto.py
from cryptography.hazmat.primitives.ciphers.aead import AESGCM
from cryptography.hazmat.primitives.kdf.pbkdf2 import PBKDF2HMAC
from cryptography.hazmat.primitives import hashes
import os, base64
_NONCE_SIZE = 12 # GCM standard (96-bit)
_KDF_ITER = 600_000
def derive_key(password: str) -> bytes:
"""PBKDF2-HMAC-SHA256 — same password + same salt = same key."""
salt = _load_or_create_salt() # 256-bit, stored at ~/.config/dotghostboard/eclipse.salt
kdf = PBKDF2HMAC(
algorithm=hashes.SHA256(),
length=32,
salt=salt,
iterations=_KDF_ITER,
)
return kdf.derive(password.encode("utf-8"))
def encrypt(plaintext: str, key: bytes) -> str:
"""AES-256-GCM → base64url token safe for SQLite TEXT columns."""
nonce = os.urandom(_NONCE_SIZE)
ciphertext = AESGCM(key).encrypt(nonce, plaintext.encode("utf-8"), None)
return base64.urlsafe_b64encode(nonce + ciphertext).decode("ascii")
def decrypt(token: str, key: bytes) -> str:
"""Raises ValueError on wrong key or tampered data."""
raw = base64.urlsafe_b64decode(token.encode("ascii"))
nonce = raw[:_NONCE_SIZE]
ct = raw[_NONCE_SIZE:]
return AESGCM(key).decrypt(nonce, ct, None).decode("utf-8")
Wire format: [ 12-byte nonce ][ ciphertext ][ 16-byte GCM auth tag ] — all base64url-encoded. The GCM tag means any tampering is detected on decryption, not silently ignored.
Password Verification Without Storing the Password
_VERIFY_TOKEN = "DOTGHOST_ECLIPSE_OK"
def save_master_password(password: str) -> None:
key = derive_key(password)
token = encrypt(_VERIFY_TOKEN, key) # store encrypted sentinel
with open(_VERIFY_FILE, "w") as f:
f.write(token)
def verify_password(password: str) -> bool:
with open(_VERIFY_FILE) as f:
stored = f.read().strip()
try:
return decrypt(stored, derive_key(password)) == _VERIFY_TOKEN
except Exception:
return False
The raw password is never stored — not even hashed. Only an encrypted sentinel string lives on disk. Delete eclipse.salt and the ciphertext becomes permanently unrecoverable.
The Lock Screen
I wanted it to feel like a real lock screen — not just a dialog you can dismiss.
# ui/lock_screen.py (key parts)
class LockScreen(QDialog):
MAX_ATTEMPTS = 5
def __init__(self, parent=None, *, setup: bool = False):
super().__init__(parent)
self.setWindowFlags(
Qt.WindowType.Dialog |
Qt.WindowType.WindowStaysOnTopHint |
Qt.WindowType.FramelessWindowHint # no title bar
)
self.setModal(True)
def keyPressEvent(self, event):
# Escape cannot close a lock screen
if event.key() != Qt.Key.Key_Escape:
super().keyPressEvent(event)
def closeEvent(self, event):
# Window manager X button is also blocked
if self._key is None:
event.ignore()
else:
super().closeEvent(event)
Three layers of protection:
-
FramelessWindowHint — no title bar, no close button
-
keyPressEvent — Escape key swallowed
-
closeEvent — WM close ignored until password accepted
Per-Item Secret Toggle
This was the UX challenge. I didn’t want to encrypt everything automatically — that would be aggressive and confusing. Instead, the user right-clicks any text card:
# ui/dashboard.py — context menu
def _on_card_context_menu(self, pos, card: ItemCard):
menu = QMenu(self)
# Only show encryption options if master password is set
# and item is a text card
if has_master_password() and card.item_type == "text":
menu.addSeparator()
if card.is_secret:
action = QAction("🔓 Remove Encryption", self)
action.triggered.connect(lambda: self._decrypt_card(card.item_id))
else:
action = QAction("🔐 Mark as Secret", self)
action.triggered.connect(lambda: self._encrypt_card(card.item_id))
menu.addAction(action)
menu.exec(card.mapToGlobal(pos))
When encrypted, the card shows an amber overlay — content is completely hidden:
# ui/widgets.py — the encrypted card face
def _build_secret_overlay(self) -> QWidget:
overlay = QFrame()
overlay.setObjectName("SecretOverlay")
overlay.setStyleSheet("""
QFrame#SecretOverlay {
background: rgba(255, 153, 0, 0.05);
border: 1px dashed #ff990055;
border-radius: 6px;
}
""")
overlay.setFixedHeight(56)
# ... lock icon + hint label
return overlay
Clicking 👁 Reveal fires a signal up to Dashboard, which decrypts using the session key and pushes the plaintext back down:
# Dashboard receives the reveal request:
def _on_reveal_requested(self, item_id: int) -> None:
if self._active_key is None:
self.statusBar().showMessage("⚠ Session is locked — unlock first.")
return
plaintext = storage.decrypt_item(item_id, self._active_key)
if plaintext:
self._cards[item_id].reveal_content(plaintext)
# ItemCard shows the plaintext:
def reveal_content(self, plaintext: str):
self._revealed_label.setText(plaintext[:120] + "…" if len(plaintext) > 120 else plaintext)
self._overlay_widget.hide()
self._revealed_label.show()
self._is_revealed = True
self._secret_btn.setText("🔒 Lock")
When the session locks, all revealed cards re-hide automatically:
# Dashboard._lock():
for card in self._cards.values():
card.on_session_locked() # re-hides revealed content
# ItemCard.on_session_locked():
def on_session_locked(self):
if self.is_secret and self._is_revealed:
self._revealed_label.hide()
self._revealed_label.setText("") # clear plaintext from memory
self._overlay_widget.show()
Auto-Lock Inactivity Timer
# Dashboard.__init__:
self._auto_lock_timer = QTimer(self)
self._auto_lock_timer.setSingleShot(True)
self._auto_lock_timer.timeout.connect(self._lock)
# Reset on any user interaction:
def mousePressEvent(self, event):
self._reset_auto_lock()
super().mousePressEvent(event)
def _reset_auto_lock(self):
minutes = self._settings.get("auto_lock_minutes", 0)
if minutes > 0 and has_master_password():
self._auto_lock_timer.start(minutes * 60 * 1000)
else:
self._auto_lock_timer.stop()
Simple and reliable — a single-shot QTimer that resets on every mouse/keyboard event.
Stealth Mode
Hide from taskbar and Alt+Tab without breaking the UI:
def _set_stealth(self, enable: bool) -> None:
import subprocess
try:
wid = hex(int(self.winId()))
if enable:
subprocess.run([
"xprop", "-id", wid,
"-f", "_NET_WM_STATE", "32a",
"-set", "_NET_WM_STATE",
"_NET_WM_STATE_SKIP_TASKBAR,_NET_WM_STATE_SKIP_PAGER",
], check=False, timeout=2, capture_output=True)
else:
subprocess.run(
["xprop", "-id", wid, "-remove", "_NET_WM_STATE"],
check=False, timeout=2, capture_output=True
)
except Exception:
pass
This sets X11 _NET_WM_STATE hints directly via xprop — works on all EWMH-compliant window managers (GNOME, KDE, XFCE, i3 with gaps, etc.).
Secure Delete
A plain os.remove() doesn’t zero out disk sectors. Eclipse overwrites first:
# core/secure_delete.py
def secure_delete(path: str, passes: int = 3) -> bool:
if not os.path.isfile(path):
return False
size = os.path.getsize(path)
if size > 0:
with open(path, "r+b") as fh:
for pass_num in range(passes):
fh.seek(0)
# Alternate: random → zeros → random
if pass_num % 2 == 1:
fh.write(b"x00" * size)
else:
fh.write(os.urandom(size))
fh.flush()
os.fsync(fh.fileno()) # force kernel flush
os.remove(path)
return True
⚠️ Note on SSDs: Wear-levelling on SSDs means software overwrite can’t guarantee forensic destruction. For maximum security, combine this with full-disk encryption (LUKS).
App Filter — Whitelist / Blacklist
Don’t capture from KeePassXC? Easy:
# core/app_filter.py
class AppFilter:
def should_capture(self) -> bool:
if not self.app_list:
return True # no filter = capture everything
identifiers = get_active_app_identifiers()
if not identifiers:
return True # fail-open if xdotool unavailable
matched = self._matches(identifiers)
return not matched if self.mode == "blacklist" else matched
def _matches(self, identifiers: set[str]) -> bool:
# Substring match: "keepass" matches "org.keepassxc.keepassxc"
return any(
app in ident
for app in self.app_list
for ident in identifiers
)
Process detection uses xdotool + /proc/<pid>/comm:
def get_active_app_identifiers() -> set[str]:
win_id = _run(["xdotool", "getactivewindow"])
if not win_id:
return set()
pid = _run(["xdotool", "getwindowpid", win_id])
identifiers = set()
# Read process name from /proc
try:
with open(f"/proc/{pid}/comm") as f:
identifiers.add(f.read().strip().lower())
except OSError:
pass
# Also check WM_CLASS for apps with wrappers
wm_class = _run(["xprop", "-id", win_id, "WM_CLASS"])
if wm_class:
match = re.search(r'"([^"]+)"', wm_class)
if match:
identifiers.add(match.group(1).lower())
return identifiers
SQLite Schema Migration
Eclipse adds one column to the existing DB — backward compatible:
# core/storage.py — init_db()
# Migration: add is_secret for Eclipse v1.4.0
try:
conn.execute(
"ALTER TABLE clipboard_items ADD COLUMN is_secret INTEGER DEFAULT 0"
)
except Exception:
pass # column already exists — safe to ignore
And the encrypt/decrypt helpers work at the storage layer:
def encrypt_item(item_id: int, key: bytes) -> bool:
"""Encrypt content in-place. Returns False if already encrypted."""
from core.crypto import encrypt as _encrypt
item = get_item_by_id(item_id)
if not item or item.get("is_secret") or item["type"] != "text":
return False
ciphertext = _encrypt(item["content"], key)
with _db() as conn:
conn.execute(
"UPDATE clipboard_items SET content = ?, is_secret = 1 WHERE id = ?",
(ciphertext, item_id)
)
return True
def decrypt_item(item_id: int, key: bytes) -> str | None:
"""Decrypt and return plaintext — does NOT modify DB."""
from core.crypto import decrypt as _decrypt
item = get_item_by_id(item_id)
if not item:
return None
if not item.get("is_secret"):
return item["content"] # not encrypted, pass through
try:
return _decrypt(item["content"], key)
except ValueError:
return None # wrong key or corrupted
The Settings UI
Eclipse gets its own tab in the Settings dialog:
Three sections:
-
🔑 Master Password — set / change / remove with current-password verification
-
⏱ Auto-Lock — spinner 0–480 min
-
🛡 App Filter — mode combo + editable process name list
About Tab
The About tab shows version info, system info (live Python/Qt versions), MIT license, and all social/community links.
Test Coverage
Eclipse ships with 28 unit tests:
pytest tests/test_eclipse.py -v
PASSED tests/test_eclipse.py::TestCrypto::test_encrypt_decrypt_roundtrip
PASSED tests/test_eclipse.py::TestCrypto::test_encrypt_produces_different_tokens_each_call
PASSED tests/test_eclipse.py::TestCrypto::test_wrong_key_raises_value_error
PASSED tests/test_eclipse.py::TestCrypto::test_tampered_ciphertext_raises
PASSED tests/test_eclipse.py::TestCrypto::test_encrypt_unicode_characters
PASSED tests/test_eclipse.py::TestCrypto::test_master_password_flow
PASSED tests/test_eclipse.py::TestCrypto::test_same_password_derives_same_key
PASSED tests/test_eclipse.py::TestSecureDelete::test_file_is_gone_after_secure_delete
PASSED tests/test_eclipse.py::TestSecureDelete::test_original_content_overwritten
PASSED tests/test_eclipse.py::TestAppFilter::test_blacklist_blocks_matched_app
PASSED tests/test_eclipse.py::TestAppFilter::test_whitelist_allows_matched_app
PASSED tests/test_eclipse.py::TestAppFilter::test_detection_failure_fails_open
PASSED tests/test_eclipse.py::TestStorageEclipse::test_encrypt_item_stores_ciphertext
PASSED tests/test_eclipse.py::TestStorageEclipse::test_decrypt_item_returns_plaintext
PASSED tests/test_eclipse.py::TestStorageEclipse::test_decrypt_wrong_key_returns_none
... 13 more ...
28 passed in 1.84s
Install & Run
Option 1 — Download a Release (Recommended)
DotGhostBoard ships pre-built binaries via GitHub Actions CI — every push to main automatically builds for 4 platforms:
| Platform |
Format |
Size |
| 🐧 Linux |
.AppImage |
~76 MB |
| 🐧 Linux |
.deb |
~60 MB |
| 🪟 Windows |
.exe |
~46 MB |
| 🍎 macOS |
.dmg |
~125 MB |
Download from the Releases page or grab the latest build artifacts directly from GitHub Actions.
Linux AppImage (quickest):
chmod +x DotGhostBoard-1.4.0-x86_64.AppImage
./DotGhostBoard-1.4.0-x86_64.AppImage
Linux .deb:
sudo dpkg -i dotghostboard_1.4.0_amd64.deb
Option 2 — OpenDesktop.org
DotGhostBoard is also published on OpenDesktop.org — the Linux app store used by KDE, GNOME, and OCS-compatible installers.
You can install it directly from the OpenDesktop page using the OCS-Install button if your distro supports it.
Option 3 — From Source
git clone https://github.com/kareem2099/DotGhostBoard
cd DotGhostBoard
python3 -m venv venv && source venv/bin/activate
pip install -r requirements.txt
python3 main.py
Requirements: Python 3.11+, PyQt6, Pillow, cryptography, xdotool
sudo apt install xdotool # Kali / Debian / Ubuntu
What’s Next — v1.5.0 Nexus
v1.5.0 Nexus (planned)
├── 📡 Local network sync (same WiFi)
├── ☁ Optional cloud backup (S3 / Rclone)
├── 📱 QR code share — scan from phone
├── 🔌 REST API mode — localhost for scripts
├── 💻 CLI companion — dotghost push / pop
└── 🧩 Plugin system
Links
Built with PyQt6, SQLite, and the cryptography library. Part of the DotSuite toolkit by FreeRave.
Star the repo if you find it useful ⭐
Avusturya, 14 yaşın altındaki çocuklar için sosyal medya yasağı getirmeyi planlıyor. Bu konuda haziran ayı sonuna kadar resmi bir yasa tasarısı hazırlamayı hedefleyen yönetim, çocukları sosyal medyanın zararlı etkilerinden korumak amacıyla kapsamlı bir önlem paketi hazırladıklarını belirtiyor. Avustralya geçtiğimiz yıl 16 yaşın altındaki çocukların sosyal medya kullanımını yasaklayan ilk ülke olmuş ve bu konuda çok sayıda ülkeye örnek olmuştu. Çocukların sosyal medya kullanımını yasaklamayı planlayan ülkeler arasında Danimarka, Fransa, Almanya, Yunanistan, Endonezya, Malezya, Slovenya, İspanya ve İngiltere de yer alıyor. Aynı zamanda Türkiye’de de 15 yaşından küçük çocukların sosyal medya kullanımının yasaklanması hedefleniyor.
Apple’ın ilk aşamada iOS, Mac, Apple TV ve Apple Watch uygulamaları geliştirmek için hazırladığı Swift programlama dili, resmi olarak Android desteği kazandı. İlk duyurusu 2025 yılında yapılan bu önemli gelişme kapsamında geliştiriciler artık Swift’i kullanarak Android için de uygulama hazırlayabilecek. Bu konuda yapılan resmi paylaşımda, “Swift 6.3 sürümü, Android’e yönelik ilk resmi Swift SDK’sını beraberinde getiriyor. Bu sayede yazılımcılar Swift ile yerel Android programları geliştirebilir, mevcut paketlerini Android desteğiyle güncelleyebilir ve Swift Java kütüphanelerini kullanarak Swift kodlarını Kotlin veya Java tabanlı mevcut uygulamalara entegre edebilirler. Bu sürüm, Swift’in platformlar arası geliştirme imkanlarını genişleten önemli bir dönüm noktasını temsil ediyor.” ifadelerine yer verildi.
